CM4532560KSB

Fixed Inductors Overview

The CM4532560KSB is a fixed inductor manufactured by ABC Taiwan Electronics Corp. It features an unshielded wirewound construction housed in an 1812 (4532 Metric) surface-mount package. The component provides an inductance of 56 µH with a maximum DC resistance of 5.5 Ohms and a current rating of 135 mA.

Fixed Inductors Feature Summary

• Unshielded wirewound design for standard electromagnetic applications
• Surface-mount 1812 footprint for automated assembly integration

Fixed Inductors Applications

• General-purpose signal filtering circuits
• Power supply input/output stages
• Electromagnetic interference suppression

Fixed Inductors Procurement Notes

Verify the manufacturer part number against official ABC Taiwan Electronics Corp documentation to ensure authenticity. Confirm RoHS compliance status and specific electrical tolerances required for your circuit design before finalizing procurement orders.

Fixed Inductors Selection Notes

Select this component when an unshielded wirewound inductor is required for space-constrained designs using the 1812 package. Ensure the 135 mA current rating and 5.5 Ohm resistance meet the specific power and efficiency requirements of the target application circuit.

Fixed Inductors Part Context

This component belongs to the fixed inductor category produced by ABC Taiwan Electronics Corp, a manufacturer specializing in electromagnetic components. The company supplies various SMD and through-hole types, including chip and power inductors, serving industries requiring reliable passive electronic elements.

Fixed Inductors Replacement Considerations

No public confirmed substitute part numbers are available in the provided source material. Verify compatibility with alternative manufacturers based on identical inductance, current rating, and physical dimensions.
