Product Detailed Parameters
- Description：FILTER RC(PI) 15 OHMS ESD SMD
- Series：-
- Mfr：onsemi
- Package：Tape & Reel (TR)
- Type：Low Pass
- Filter Order：2nd
- Technology：RC (Pi)
- Number of Channels：2
- Center / Cutoff Frequency：-
- Attenuation Value：-
- Resistance - Channel (Ohms)：15
- Values：R = 15Ohms, C = 5000pF
- ESD Protection：Yes
- Operating Temperature：-40°C ~ 85°C
- Applications：Audio
- Voltage - Rated：-
- Mounting Type：Surface Mount
- Package / Case：5-UFBGA, WLCSP
- Size / Dimension：0.047" L x 0.031" W (1.20mm x 0.80mm)
- Height：0.025" (0.64mm)
- Current：-
- Grade：-
- Qualification：-
Download product information
Overview
The CM6205 is an EMI/RFI filter with integrated ESD protection designed for audio applications. It utilizes a PI-filter topology consisting of RC networks. The component is fully compliant with IEC 61000-4-2 standards and meets RoHS II requirements. It is packaged in a surface-mount configuration suitable for compact electronic designs.
Feature Summary
- Integrates EMI filtering and ESD protection in a single package
- Compliant with IEC 61000-4-2 standards
- RoHS II compliant construction
Applications
- Audio circuits requiring EMI suppression
- ESD protection for audio lines
Procurement Notes
Verify current availability status as the CM6205 is listed as obsolete or no longer manufactured by onsemi. Confirm end-of-life documentation and check for authorized distributors holding remaining stock if immediate procurement is required. Ensure compliance with local tariff regulations when importing.
Selection Notes
Select this component only if legacy compatibility is required, as it is discontinued. Evaluate alternative EMI filters with integrated ESD protection that are currently in production. Consider modern packages and updated compliance standards when designing new systems.
Part Context
The CM6205 belongs to onsemi's portfolio of passive components focused on signal integrity and protection. It serves as a specialized solution for audio interfaces where electromagnetic interference and electrostatic discharge pose risks to circuit performance and reliability.
Replacement Considerations
Public confirmed substitute part numbers are not available in the provided data. As the component is obsolete, consult onsemi for recommended next-generation replacements or equivalent third-party solutions.
