CM6350-334

Common Mode Chokes Overview

The Delevan CM6350-334 is a surface mount common mode choke designed for filtering electromagnetic interference in two-line circuits. It features an inductance of 330 µH measured at 10 kHz with a tolerance of 25%. The component supports a maximum current rating of 1.8 A and exhibits a maximum DC resistance (DCR) of 40 mΩ. This SMD device is suitable for applications requiring compact filtering solutions with specific impedance characteristics.

Common Mode Chokes Feature Summary

• Surface mount construction for automated assembly
• Two-line common mode filtering capability
• RoHS compliant manufacturing

Common Mode Chokes Applications

• Power line filtering
• Signal integrity protection in electronic circuits
• Electromagnetic interference suppression

Common Mode Chokes Procurement Notes

Verify the exact suffix designation, as variants such as R600 or R350 may exist within the CM6350 series. Confirm that the 1.8 A current rating and 40 mΩ DCR align with your circuit requirements. Ensure the surface mount package footprint matches your PCB design constraints before finalizing procurement orders.

Common Mode Chokes Selection Notes

Select this component when a 330 µH inductance value is required for common mode noise reduction. The 1.8 A current rating makes it suitable for moderate power applications. Consider the 40 mΩ DCR impact on voltage drop and thermal performance. Verify compatibility with reflow soldering profiles typical for surface mount components.

Common Mode Chokes Part Context

The CM6350 series represents Delevan's range of surface mount common mode chokes. These components are engineered to provide effective noise suppression in compact form factors. The series offers various inductance values to suit different filtering needs while maintaining consistent physical dimensions for board layout flexibility.

Common Mode Chokes Replacement Considerations

Publicly confirmed substitute part numbers for the CM6350-334 are not available in the provided documentation. Consult manufacturer cross-reference guides for potential alternatives if direct replacement is necessary.
