CM6350-684

Common Mode Chokes Overview

The Delevan CM6350-684 is a surface-mount common mode choke designed for signal line filtering. It features an inductance of 680 µH with a tolerance of ±25%. The component supports a maximum DC current of 1.2 A and has a maximum DC resistance of 90 mΩ. Physical dimensions are 0.36 inches by 0.36 inches by 0.2 inches. It utilizes SMD/SMT termination types and is packaged in bulk quantities.

Common Mode Chokes Feature Summary

• Surface mount construction for automated PCB assembly
• Dual-line common mode filtering capability
• Compact footprint suitable for space-constrained designs

Common Mode Chokes Applications

• Signal line noise suppression
• Data interface protection
• Common mode interference reduction in electronic circuits

Common Mode Chokes Procurement Notes

Verify the specific manufacturer designation, as API Delevan products may be listed under various corporate entities. Confirm RoHS compliance status directly with the supplier documentation, as some listings indicate lead-free status while others may vary. Ensure the package type matches the required bulk or tape-and-reel configuration for your manufacturing process.

Common Mode Chokes Selection Notes

Select this component when a 680 µH inductance at 10 kHz is required for common mode noise attenuation. Ensure the operating current does not exceed 1.2 A to maintain performance. Verify that the 90 mΩ DCR meets the voltage drop requirements of the circuit design. Check physical clearance against the 0.36 x 0.36 inch footprint.

Common Mode Chokes Part Context

This part belongs to the CM6350 series of surface mount common mode chokes from Delevan. The series offers various inductance values tailored for different filtering needs. These components are engineered for high reliability in compact electronic assemblies requiring effective electromagnetic interference mitigation on dual-line configurations.

Common Mode Chokes Replacement Considerations

Direct substitutes include other CM6350 series variants with similar electrical characteristics. Cross-reference with API Delevan documentation for equivalent part numbers offering comparable inductance and current ratings.
