CM7060R301R-10

Common Mode Chokes Overview

CM7060R301R-10 is a two-line common mode choke manufactured by Laird-Signal Integrity Products. It provides an impedance of 300 Ohms at 100 MHz and supports a maximum current rating of 5 Amperes. The component features a low DC resistance (DCR) of 10 mOhm, ensuring minimal signal loss in power or data lines. Designed for surface mount installation, it utilizes a compact package suitable for automated assembly processes.

Common Mode Chokes Feature Summary

• Dual-line architecture designed for effective common mode noise suppression
• High current handling capability with low insertion loss characteristics
• Surface mount construction optimized for high-volume manufacturing integration

Common Mode Chokes Applications

• Power line filtering in electronic equipment
• Data bus protection against electromagnetic interference
• Signal integrity enhancement in communication interfaces

Common Mode Chokes Procurement Notes

Verify the specific package dimensions and terminal configuration against your PCB footprint before ordering. Confirm that the 5A current rating meets your circuit requirements under expected operating temperatures. Ensure compatibility with your reflow soldering profile to maintain component integrity during assembly.

Common Mode Chokes Selection Notes

Select this component when dual-channel noise suppression is required for high-current applications. The low DCR value makes it suitable for sensitive signal paths where voltage drop must be minimized. Consider the physical size constraints of your design relative to other available common mode chokes in the series.

Common Mode Chokes Part Context

This part belongs to Laird's CM series of common mode chokes, which are engineered for EMI suppression in both power and signal lines. The series offers various impedance and current ratings to suit different filtering needs while maintaining consistent performance standards across the product line.

Common Mode Chokes Replacement Considerations

Direct substitutes include CM7060N102R-10 and CM7060M132R-10 from the same manufacturer. Verify impedance values and current ratings match your design specifications before swapping components.
