CM7560-185

Common Mode Chokes Overview

The CM7560-185 is a through-hole common mode choke manufactured by API Delevan. It features an inductance of 1.8 mH at 1 kHz with a tolerance of ±25%. The component has a maximum DC resistance of 125 milliohms and a current rating of 1.7 A. It operates within a temperature range of -55°C to 125°C. Physical dimensions are 27.2 mm in length, 21.8 mm in width, and 21.1 mm in height. The device utilizes a ferrite core and is unshielded.

Common Mode Chokes Feature Summary

• Provides common mode noise suppression for data lines
• Utilizes a ferrite core for high-frequency attenuation
• Designed for through-hole PCB mounting

Common Mode Chokes Applications

• Data line filtering
• Common mode noise reduction in electronic circuits

Common Mode Chokes Procurement Notes

Verify the specific manufacturer designation, as API Delevan products may be listed under either name. Confirm that the lead spacing matches the target PCB footprint requirements before procurement. Ensure compliance with RoHS standards if required by the end application specifications.

Common Mode Chokes Selection Notes

Select this component when a 1.8 mH inductance value is required for common mode applications. The 1.7 A current rating suits moderate power data lines. Verify that the through-hole package fits the assembly constraints and that the unshielded design does not interfere with nearby sensitive components.

Common Mode Chokes Part Context

This part belongs to the CM7560 series of common mode chokes from API Delevan. The series offers various inductance values tailored for different filtering needs. These components are passive filters designed to suppress electromagnetic interference on differential signal lines.

Common Mode Chokes Replacement Considerations

Cross-reference with other CM7560 series variants such as CM7560-155 or CM7560-275 if different inductance values are acceptable. Ensure any substitute maintains the same physical dimensions and current rating to fit existing board layouts.
