CM7560-684

Common Mode Chokes Overview

The Delevan CM7560-684 is a through-hole common mode filter choke designed for PCB mounting. It features a nominal inductance of 680 µH with a tolerance of ±25%. The component supports a maximum DC current of 3.5 A and exhibits a maximum DC resistance of 40 mΩ. It operates within a temperature range of -55°C to +125°C. Physical dimensions are 21.8 mm in length, 27.2 mm in width, and 21.1 mm in height.

Common Mode Chokes Feature Summary

• Provides common mode noise suppression via high inductance filtering.
• Supports high current handling capabilities up to 3.5 A.
• Utilizes radial through-hole termination for secure PCB integration.

Common Mode Chokes Applications

• Power supply input filtering
• EMI suppression in electronic circuits
• Common mode noise reduction in signal lines

Common Mode Chokes Procurement Notes

Verify the specific manufacturer part number against official Delevan documentation to ensure accuracy. Confirm that the required inductance value and current ratings align with the design specifications. Check for any RoHS compliance status updates or alternative packaging options if available from authorized distributors.

Common Mode Chokes Selection Notes

Select this component when a high-inductance common mode choke is required for through-hole applications. Ensure the circuit design accommodates the physical footprint of 21.8 mm by 27.2 mm. Verify that the operating environment stays within the specified -55°C to +125°C temperature range for reliable performance.

Common Mode Chokes Part Context

This component belongs to the CM7560 series of common mode chokes manufactured by Delevan. The series offers various inductance values tailored for different filtering requirements while maintaining consistent physical dimensions and mounting styles for standardized PCB layouts.

Common Mode Chokes Replacement Considerations

Consult official Delevan cross-reference data for verified substitutes. Ensure any replacement matches the 680 µH inductance, 3.5 A current rating, and radial through-hole package constraints.
