CMF4-1004HCLF

Common Mode Chokes Overview

The CMF4-1004HCLF is a dual-line common mode choke from the CMF4HC series by Gowanda Electronics. It features an inductance of 1 mH at 10 kHz and a maximum DC resistance of 18 mOhm. The component supports a current rating of 5.7 A and operates within a temperature range of -55°C to 125°C. It utilizes a through-hole mounting style and is supplied in bulk packaging.

Common Mode Chokes Feature Summary

• Dual-line configuration for effective common mode noise suppression
• High current handling capability suitable for power line applications
• Robust thermal performance across extended operating temperatures

Common Mode Chokes Applications

• Power supply input filtering
• EMI suppression in electronic equipment
• Signal integrity protection in data lines

Common Mode Chokes Procurement Notes

Verify the specific suffix 'CLF' against official Gowanda documentation to confirm lead-free compliance and exact physical dimensions. Ensure the required current rating of 5.7 A aligns with the target circuit design before procurement. Confirm that the through-hole package matches the PCB layout specifications.

Common Mode Chokes Selection Notes

Select this component when high current capacity and low DC resistance are critical for minimizing power loss. The 1 mH inductance value provides effective filtering at 10 kHz. Consider the through-hole form factor if surface space is limited but mechanical stability is required.

Common Mode Chokes Part Context

This part belongs to the CMF4HC series, designed for general-purpose common mode chokes. The series offers various inductance values and current ratings to suit different power and signal processing requirements. The CMF4-1004HCLF specifically targets applications requiring robust noise reduction in high-current environments.

Common Mode Chokes Replacement Considerations

Consult Gowanda Electronics for direct substitutes within the CMF4HC series. Verify equivalent inductance, current rating, and DCR values. Cross-reference pinout and mechanical dimensions to ensure compatibility with existing assemblies.
