CMLE063T-R36MS

Fixed Inductors Overview

The CMLE063T-R36MS is a shielded surface-mount power inductor from the Delta Electronics/Cyntec CMLE063T series. It features a metal core and offers an inductance of 360 nH with a tolerance of ±20%. The component supports a maximum current rating of 25 A, including saturation current (Isat) of 25 A. Its maximum DC resistance (DCR) is 2.55 mOhm. Physical dimensions are 7.25 mm length, 6.60 mm width, and 3.00 mm height. It operates within a temperature range of -55°C to 125°C and is tested at 100 kHz.

Fixed Inductors Feature Summary

• Shielded construction utilizing a metal core to minimize electromagnetic interference.
• High current handling capability with 25 A saturation rating for robust power delivery.
• Low DC resistance design optimized for efficient power conversion applications.

Fixed Inductors Applications

• Point-of-load (POL) voltage regulation modules
• High-density DC-DC converter output filtering
• Server and workstation power supply stages

Fixed Inductors Procurement Notes

Verify the manufacturer part number CMLE063T-R36MS against official Delta Electronics or Cyntec documentation to confirm specifications. Ensure compatibility with surface-mount assembly processes. Check for RoHS compliance status and moisture sensitivity level requirements prior to integration into production workflows.

Fixed Inductors Selection Notes

Select this component for designs requiring high current density in compact footprints. The 360 nH value suits high-frequency switching applications. Evaluate thermal management needs given the 25 A rating and low DCR characteristics. Confirm that the nonstandard package fits the available PCB real estate constraints.

Fixed Inductors Part Context

This part belongs to the CMLE063T series of fixed power inductors manufactured by Delta Electronics/Cyntec. The series is characterized by shielded magnetic structures and metal cores designed for SMD mounting. These components target demanding power electronics environments requiring reliability under high load conditions.

Fixed Inductors Replacement Considerations

Cross-reference with other CMLE063T variants such as CMLE063T-R22MS or CMLE063T-1R5MS if different inductance values are required. Verify pinout and dimensional compatibility before substituting with generic equivalents.
