CMMR1F-02 TR PBFREE is listed in the Single Diodes range at ChipApex. The manufacturer field lists Central Semiconductor Corp. Its product description is 1A 200V SMD RECTIFIER-FAST RECOV. Review the specifications below when checking this part for your BOM.
Single Diodes specifications for CMMR1F-02 TR PBFREE
- Description：1A 200V SMD RECTIFIER-FAST RECOV
- Series：-
- Mfr：Central Semiconductor Corp
- Package：Tape & Reel (TR)
- Technology：Standard
- Voltage - DC Reverse (Vr) (Max)：200 V
- Current - Average Rectified (Io)：1A
- Voltage - Forward (Vf) (Max) @ If：1.3 V @ 1 A
- Speed：Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr)：150 ns
- Current - Reverse Leakage @ Vr：1 µA @ 800 V
- Capacitance @ Vr, F：9pF @ 4V, 1MHz
- Mounting Type：Surface Mount
- Package / Case：SOD-123F
- Supplier Device Package：SOD-123F
- Operating Temperature - Junction：-65°C ~ 150°C
- Grade：-
- Qualification：-
Single Diodes datasheet and documents for CMMR1F-02 TR PBFREE
Single Diodes Overview
The CMMR1F-02 TR PBFREE is a fast recovery rectifier diode manufactured by Central Semiconductor Corp. It features a maximum DC reverse voltage of 200 V and an average rectified forward current of 1 A. The component utilizes a surface-mount SOD-123F package configuration. Key electrical specifications include a capacitance of 6 pF measured at 4 V and 1 MHz. The device is supplied in a tape and reel format, designated by the suffix TR.
Single Diodes Feature Summary
- Fast recovery rectification capability for efficient switching applications
- Surface-mount construction utilizing the compact SOD-123F package
- Lead-free manufacturing compliant with RoHS standards
Single Diodes Applications
- High-frequency power supply circuits
- General-purpose rectification in surface-mount assemblies
- DC-DC converter output stages
Single Diodes Procurement Notes
Verify the specific ordering suffix to confirm the tape and reel packaging configuration. Ensure the procurement documentation explicitly references the lead-free (PBFREE) designation to meet environmental compliance requirements. Cross-reference the manufacturer part number against official distributor catalogs to confirm availability status before finalizing orders.
Single Diodes Selection Notes
Select this component when a 200 V reverse voltage rating and 1 A continuous current capacity are required within a small surface-mount footprint. The SOD-123F package offers space efficiency compared to larger axial leads. Verify that the fast recovery characteristics align with the target circuit's switching frequency requirements.
Single Diodes Part Context
This component belongs to the CMMR1F series of fast recovery rectifiers from Central Semiconductor Corp. The series provides standardized solutions for surface-mount rectification needs. The specific model integrates high-speed switching performance into a compact form factor suitable for modern electronic assembly techniques.
Single Diodes Replacement Considerations
Consult the Central Semiconductor Index/Cross Reference document for verified substitute part numbers. Ensure any replacement maintains identical voltage, current, and package specifications.
