CMSH3-60MA TR13 PBFREE

$0.12

Description：3A 60V SMD RECTIFIER-SCHOTTKY (>
Series：-
Mfr：Central Semiconductor Corp
Package：Tape & Reel (TR)

SKU:7bb841da8ea0 Category: Single Diodes Brand: Central Semiconductor Corp

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

CMSH3-60MA TR13 PBFREE is listed in the Single Diodes range at ChipApex. The manufacturer field lists Central Semiconductor Corp. Its product description is 3A 60V SMD RECTIFIER-SCHOTTKY (>. Review the specifications below when checking this part for your BOM.

Single Diodes specifications for CMSH3-60MA TR13 PBFREE

Description：3A 60V SMD RECTIFIER-SCHOTTKY (>
Series：-
Mfr：Central Semiconductor Corp
Package：Tape & Reel (TR)
Technology：Schottky
Voltage - DC Reverse (Vr) (Max)：60 V
Current - Average Rectified (Io)：3A
Voltage - Forward (Vf) (Max) @ If：700 mV @ 3 A
Speed：Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr)：-
Current - Reverse Leakage @ Vr：500 µA @ 60 V
Capacitance @ Vr, F：-
Mounting Type：Surface Mount
Package / Case：DO-214AC, SMA
Supplier Device Package：SMA
Operating Temperature - Junction：-65°C ~ 150°C
Grade：-
Qualification：-

Single Diodes datasheet and documents for CMSH3-60MA TR13 PBFREE

CMSH3-60MA TR13 PBFREE

Single Diodes Overview

The CMSH3-60MA TR13 PBFREE is a single-element, one-phase silicon Schottky rectifier diode manufactured by Central Semiconductor. It features an SMB (DO-214AA) surface-mount package with two pins. The device supports a maximum average forward rectified current of 3 A and a repetitive peak reverse voltage (VRRM) of 60 V. Key electrical parameters include a maximum non-repetitive peak forward surge current of 80 A and a maximum forward voltage of 0.75 V. It operates within a temperature range of -65 °C to +150 °C junction temperature.

Single Diodes Feature Summary

Utilizes silicon Schottky technology for low forward voltage drop characteristics
Designed for high reliability in general-purpose applications
Constructed in a compact plastic/epoxy rectangular SMA-style surface-mount package

Single Diodes Applications

General-purpose rectification circuits
DC-DC converter output stages
Free-wheeling diodes in inductive load switching

Single Diodes Procurement Notes

Verify the specific suffix 'MA' against official datasheets to confirm marking codes or tape-and-reel specifications. Ensure the component meets RoHS compliance requirements if mandated by your assembly standards. Cross-reference the manufacturer part number with authorized distributors to confirm availability and authenticity before procurement.

Single Diodes Selection Notes

Select this component when a 3 A current rating and 60 V blocking voltage are required in an SMB package. Consider the 0.75 V maximum forward voltage for efficiency calculations. Verify that the operating environment stays within the specified -65 °C to +150 °C temperature range. Compare surge current capabilities against circuit inrush requirements.

Single Diodes Part Context

This part belongs to the Central Semiconductor CMSH series of Schottky rectifiers. The series offers various current ratings and voltage options in surface-mount packages like SMA and SMB. These diodes are designed to provide efficient power conversion with reduced heat generation compared to standard PN junction rectifiers.
