CN4026M00008T1521017

Crystals Overview

The CN4026M00008T1521017 is a surface-mount crystal resonator manufactured by Hefei Jingweite Electronics Co., Ltd. It operates at a fundamental frequency of 26 MHz with a frequency tolerance of ±10ppm. The component features an 8pF load capacitance and an equivalent series resistance (ESR) of 80 Ohms. It is housed in a compact 4-SMD, No Lead package suitable for automated assembly. The device supports a standard operating temperature range from -40°C to +85°C, ensuring reliable performance across various environmental conditions.

Crystals Feature Summary

• Surface mount design for efficient PCB integration
• Stable frequency generation with precise tolerance
• Wide operational temperature capability

Crystals Applications

• Clock signal generation for microcontrollers
• Timing reference for communication interfaces
• Frequency control in consumer electronics

Crystals Procurement Notes

Verify the exact datasheet specifications directly with Hefei Jingweite Electronics Co., Ltd. or authorized distributors before procurement. Confirm that the 4-SMD package dimensions and pin configuration match your PCB footprint requirements. Ensure the operating temperature range meets your specific application environment standards.

Crystals Selection Notes

Select this component when a 26 MHz timing source is required with moderate stability. The 80 Ohm ESR and 8pF load capacitance must align with the oscillator circuit design. Consider the 4-SMD form factor for space-constrained layouts requiring lead-free compliance.

Crystals Part Context

This part belongs to the quartz crystal resonator product line offered by Hefei Jingweite Electronics Co., Ltd., a manufacturer specializing in frequency control devices. The company focuses on R&D and production of high-reliability quartz components for industrial and commercial applications.

Crystals Replacement Considerations

No public substitute part numbers are documented for this specific model. Cross-reference only if identical electrical parameters and package dimensions are confirmed by the original manufacturer.
