CP-01316110

Headers, Male Pins Overview

The CP-01316110 is a male pin header connector from the CP-01 series by Cvilux USA. It features a 16-position, dual-row configuration with a 4.20mm (0.165 inch) pitch. Designed for through-hole mounting, it utilizes brass contacts with tin plating and a natural PA66 nylon insulation rated UL94 V-2. The connector supports a 9A current rating at 600VAC, operating within -25°C to 85°C. It includes four-wall shielding and solder termination.

Headers, Male Pins Feature Summary

• Dual-row layout providing high-density interconnect capability
• Four-wall shielding structure for enhanced signal protection
• Through-hole termination ensuring secure PCB attachment

Headers, Male Pins Applications

• High-density board-to-board connections
• Industrial control system interfaces
• Power distribution modules

Headers, Male Pins Procurement Notes

Verify the specific part number CP-01316110 against official Cvilux datasheets to confirm the 16-position dual-row specification. Ensure compatibility with mating receptacles having a matching 4.20mm pitch. Confirm that the natural color and PA66 material meet environmental requirements for the target application.

Headers, Male Pins Selection Notes

Select this component when a dual-row header with a wide 4.20mm spacing is required for robust power or signal routing. The tin-plated brass contacts offer reliable conductivity, while the UL94 V-2 rated insulation provides necessary fire safety. Consider the through-hole mounting style for applications requiring mechanical stability over surface-mount alternatives.

Headers, Male Pins Part Context

This connector belongs to the CP-01 series, which focuses on general-purpose rectangular headers. Unlike the CP35 series designed for higher power applications, the CP-01 series emphasizes standard density and cost-effective solutions for various electronic assemblies using common materials like PA66.

Headers, Male Pins Replacement Considerations

Direct substitutes must match the 16-pin, dual-row, 4.20mm pitch specification. Verify that alternative manufacturers offer comparable current ratings and thermal performance. Ensure the replacement maintains the same through-hole footprint and shielding characteristics.
