CP206-2N4393-CT20

Description：JFET N-CH 40V 1=20PCS
Series：-

SKU:7df96fae4dcc Category: JFETs Brand: Central Semiconductor Corp

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：JFET N-CH 40V 1=20PCS
Series：-
Mfr：Central Semiconductor Corp
Package：Tray
FET Type：N-Channel
Voltage - Breakdown (V(BR)GSS)：40 V
Drain to Source Voltage (Vdss)：40 V
Current - Drain (Idss) @ Vds (Vgs=0)：5 mA @ 20 V
Current Drain (Id) - Max：50 mA
Voltage - Cutoff (VGS off) @ Id：500 mV @ 1 nA
Input Capacitance (Ciss) (Max) @ Vds：14pF @ 20V
Resistance - RDS(On)：100 Ohms
Power - Max：1.8 W
Operating Temperature：-65°C ~ 175°C (TJ)
Mounting Type：Surface Mount
Package / Case：Die
Supplier Device Package：Die
Grade：-
Qualification：-

Download product information

CP206-2N4393-CT20

Overview

The CP206-2N4393-CT20 is an N-channel Junction Field-Effect Transistor (JFET) manufactured by Central Semiconductor Corp. It is designed for demanding analog switching applications and specialized amplifier circuits. The device features low on-resistance, fast switching capabilities, high off-isolation with low leakage, and low capacitance. These characteristics result in low error voltage, negligible off-error, excellent accuracy, good frequency response, and low glitches. The component eliminates the need for additional buffering in circuit designs.

Feature Summary

Low On-Resistance
Fast Switching
High Off-Isolation
Low Capacitance
Low Insertion Loss

Applications

Analog Switches
Choppers
Sample-and-Hold
Normally 'On' Switches
Current Limiters
Commutators

Procurement Notes

Verify the manufacturer designation as Central Semiconductor Corp against the specific part number CP206-2N4393-CT20. Confirm that the suffix CT20 corresponds to the intended tape-and-reel packaging configuration for automated assembly. Ensure the component meets the required MIL-S-19500 processing standards if hermetic sealing is necessary for the application environment.

Selection Notes

Select this component for applications requiring high-speed analog performance and low glitch generation. The low on-resistance and high off-isolation make it suitable for precision signal routing. Consider the package type availability for automated assembly when designing the PCB layout. Evaluate the thermal requirements against the maximum power dissipation limits specified in the official datasheet.

Part Context

This part belongs to the 2N/PN/SST4391 series of N-channel JFETs. The series includes variants such as the 2N4391, 2N4392, and 2N4393. The 2N variant typically refers to the hermetically-sealed TO-206AA (TO-18) can package. Other series members are available in TO-226AA (TO-92) and TO-236 (SOT-23) packages for different mounting and automation needs.

Replacement Considerations

Direct substitutes within the same series include the 2N4391 and 2N4392. Cross-manufacturer equivalents may exist from vendors like Vishay or Linear Integrated Systems, but pinout and electrical parameter verification is essential. Ensure any replacement matches the N-channel configuration and hermetic sealing requirements if applicable.
