CP3502P1V00-S-NH

Headers, Male Pins Overview

The CP3502P1V00-S-NH is a board mount header manufactured by Cvilux USA. It features a vertical orientation with two positions arranged in a single row. The connector utilizes a 3mm (0.118 inch) pitch for contact spacing. Designed for through-hole termination, it ensures secure board mounting. The component is constructed with brass contacts and polyamide insulation materials.

Headers, Male Pins Feature Summary

• Vertical shrouded header design for board-to-board connectivity
• Through-hole termination method for stable mechanical attachment
• Lead-free soldering process compatibility with halogen-free construction

Headers, Male Pins Applications

• Consumer electronics internal connections
• General-purpose wire-to-board interfaces
• Low-current signal transmission circuits

Headers, Male Pins Procurement Notes

Verify the specific pin count matches the required circuit design before procurement. Confirm that the through-hole mounting style aligns with the printed circuit board layout capabilities. Ensure the lead-free and halogen-free specifications meet environmental compliance requirements for the target assembly. Cross-reference the manufacturer part number to avoid confusion with similar series components.

Headers, Male Pins Selection Notes

Select this component when a low-profile vertical header is required for two-position connections. The 3mm pitch offers wider spacing compared to standard 2.54mm headers, potentially aiding in high-voltage isolation or ease of manual assembly. Consider the shrouded design if protection against accidental shorting during mating is necessary. Evaluate the through-hole requirement against available surface-mount alternatives if space constraints dictate otherwise.

Headers, Male Pins Part Context

This part belongs to the CP35 series of connectors from Cvilux Corporation. The series focuses on board mount headers for consumer electronics applications. The suffix NH indicates compliance with lead-free soldering processes and halogen-free material standards. The 'S' designation typically denotes SMT type in some contexts, but datasheets specify through-hole for this specific model configuration.

Headers, Male Pins Replacement Considerations

Direct substitutes must match the 2-position, 3mm pitch, and vertical through-hole form factor. Verify that replacement parts maintain the same shrouded design and material flammability ratings. Check for equivalent lead-free certification if environmental regulations apply. Generic headers may lack the specific shroud geometry required for proper mating.
