CP3504P1V00-NH

Headers, Male Pins Overview

The CP3504P1V00-NH is a single-row header connector from the CP35 series, manufactured by Cvilux USA. It features four positions with a 3.00mm (0.118 inch) pitch and utilizes square male pin contacts. Designed for through-hole mounting, it supports board-to-cable or wire applications. The housing is constructed from halogen-free PA6T reinforced with glass fiber, rated UL94 V-0, and operates within a temperature range of -40°C to 105°C. Electrical ratings include 7A current and 600VAC voltage.

Headers, Male Pins Feature Summary

• Features a slide-lock mechanism for secure mating retention.
• Constructed with halogen-free polyamide insulation for enhanced safety compliance.
• Includes a four-wall shielded cover design for improved protection.

Headers, Male Pins Applications

• Board-to-cable interconnections
• Wire-to-board connections
• Industrial control systems

Headers, Male Pins Procurement Notes

Verify the specific part number against official Cvilux USA documentation to confirm availability and specifications. Ensure that the selected variant matches the required contact configuration and insulation material properties. Cross-reference datasheets for accurate environmental ratings and mechanical dimensions before finalizing procurement decisions.

Headers, Male Pins Selection Notes

Select this component based on the requirement for a 4-position, single-row header with a 3.00mm pitch. Consider the through-hole termination method and the need for a slide-lock feature. Evaluate the operating temperature range and voltage ratings against the application's electrical demands to ensure reliable performance under specified conditions.

Headers, Male Pins Part Context

This connector belongs to the CP35 series of power connectors designed for robust industrial applications. The series offers various position counts and locking mechanisms to accommodate different assembly needs. The CP3504P1V00-NH specifically provides a compact solution for high-density board-to-wire connections requiring reliable electrical continuity.

Headers, Male Pins Replacement Considerations

Consult official manufacturer substitution lists for verified alternatives. Generic cross-references may not match the specific slide-lock mechanism or insulation material requirements. Verify dimensional compatibility and electrical ratings before considering any substitute components.
