CP3508P1V00-S-NH

Headers, Male Pins Overview

The CP3508P1V00-S-NH is a rectangular power connector header manufactured by Cvilux USA. It features 8 positions arranged in a single row with a 0.118-inch (3.00mm) pitch. The connector utilizes male pin contacts made of brass with tin plating, designed for press-fit termination. Rated at 600VAC and 7A, it employs a PA6T insulation material rated UL94 V-0. The housing is black, and the unit supports through-hole mounting with a slide-lock fastening mechanism.

Headers, Male Pins Feature Summary

• Single-row configuration with eight contact positions
• Slide-lock fastening mechanism for secure mating
• Through-hole installation style for board mounting
• Tin-plated brass contacts for reliable conductivity

Headers, Male Pins Applications

• Board-to-cable interconnections
• Power distribution modules
• Industrial control systems
• Consumer electronics assemblies

Headers, Male Pins Procurement Notes

Verify that the specific suffix 'S' corresponds to the single-row variant within the CP35 series documentation. Confirm that the required mating housing is selected from the compatible receptacle housings listed in the official datasheet. Ensure that the appropriate crimping tools are available for the specified terminal types to guarantee proper assembly and connection integrity.

Headers, Male Pins Selection Notes

Select this component when a single-row header with an 8-position count and 3.00mm spacing is required. The 600VAC rating and 7A current capacity suit moderate power applications. Verify compatibility with mating receptacles sharing the same pitch and locking style. Consider the through-hole mounting requirement and the specific insulation material properties for the operating environment.

Headers, Male Pins Part Context

This part belongs to the CP35 series of rectangular power connectors produced by Cvilux USA. The series includes various configurations of headers and housings with consistent 3.00mm spacing. The CP35 series is designed for robust board-to-wire connections, offering multiple row options and locking mechanisms to accommodate diverse assembly needs across industrial and consumer sectors.

Headers, Male Pins Replacement Considerations

Direct substitutes include other single-row 8-position headers with identical 3.00mm pitch and similar electrical ratings. Compatible alternatives must match the through-hole mounting style and male pin contact type. Verify that any replacement part maintains the same UL94 V-0 flammability rating and voltage/current specifications.
