CP455530B

Overview

The nVent Hoffman CP455530B is a Concept HMI steel electrical enclosure designed for wall mounting. It features a landscape orientation with dimensions of 450x550x300mm (17.72 x 21.65 x 11.8 inches). The unit is constructed from 14-gauge steel with a light gray polyester powder paint finish and includes blue trim accents on the integral handle extrusions. Rated NEMA Type 4, it provides durable protection for human-machine interface equipment.

Feature Summary

• NEMA Type 4 rated construction for environmental protection
• Concept HMI series design optimized for human-machine interface applications
• Single-point cover latching mechanism for secure access
• Integral handle extrusions with distinct blue accent coloring

Applications

• Human-Machine Interface (HMI) panel integration
• Industrial control system housing
• Wall-mounted equipment protection in harsh environments
• Automation interface stations requiring NEMA Type 4 rating

Procurement Notes

Verify that the specific order matches the Concept HMI series designation rather than standard industrial enclosures. Confirm the presence of the aluminum front plate and blue handle extrusions as these are specific to this model variant. Ensure the NEMA Type 4 rating aligns with the intended environmental exposure requirements before finalizing procurement.

Selection Notes

Select this model when a landscape-oriented HMI enclosure is required with integrated handle aesthetics. The 14-gauge steel thickness offers structural rigidity suitable for wall mounting. Consider the specific dimensional constraints of 450x550x300mm to ensure fit within the designated panel space. The light gray finish complements standard industrial control cabinet interiors.

Part Context

This component belongs to the nVent Hoffman Concept HMI series, which specializes in enclosures tailored for human-machine interface installations. Unlike general-purpose boxes, this series integrates aesthetic elements like colored handle extrusions while maintaining industrial durability standards. It represents a specialized subset of Hoffman's broader enclosure portfolio focused on operator interaction points.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Verify compatibility with existing mounting hardware if replacing older models. Consult official nVent Hoffman catalogs for direct equivalents within the Concept HMI line.
