Product Detailed Parameters
- Description：MOSFET N-CH 60V SOT89
- Series：-
- Mfr：Littelfuse Inc.
- Package：Tape & Reel (TR),Cut Tape (CT)
- FET Type：N-Channel, Depletion Mode
- Technology：MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss)：60 V
- Current - Continuous Drain (Id) @ 25°C：-
- Drive Voltage (Max Rds On, Min Rds On)：0V
- Rds On (Max) @ Id, Vgs：1Ohm @ 300mA, 0V
- Vgs(th) (Max) @ Id：-
- Gate Charge (Qg) (Max) @ Vgs：-
- Vgs (Max)：±15V
- Input Capacitance (Ciss) (Max) @ Vds：-
- FET Feature：-
- Power Dissipation (Max)：1.1W (Ta)
- Operating Temperature：-55°C ~ 125°C (TJ)
- Grade：-
- Qualification：-
- Mounting Type：Surface Mount
- Supplier Device Package：SOT-89
- Package / Case：TO-243AA
Download product information
