CQB150-300S12

CQB150-300S12 is listed in the DC DC Converters range at ChipApex. The manufacturer field lists Cincon Electronics Co. LTD. Its product description is DC DC CONVERTER 12V 150W. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for CQB150-300S12

• Description：DC DC CONVERTER 12V 150W
• Series：CQB150-300S (150W)
• Mfr：Cincon Electronics Co. LTD
• Package：Tray
• Type：Isolated Module
• Number of Outputs：1
• Voltage - Input (Min)：180V
• Voltage - Input (Max)：425V
• Voltage - Output 1：12V
• Voltage - Output 2：-
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：12.5A
• Power (Watts)：150 W
• Voltage - Isolation：3 kV
• Applications：ITE (Commercial)
• Features：Remote On/Off, OCP, OTP, OVP, SCP, UVLO
• Operating Temperature：-40°C ~ 105°C (With Derating)
• Efficiency：89%
• Mounting Type：Through Hole
• Package / Case：Module
• Size / Dimension：2.28" L x 1.45" W x 0.50" H (57.9mm x 36.8mm x 12.7mm)
• Supplier Device Package：Module
• Control Features：Enable, Active High
• Approval Agency：CE, cURus
• Standard Number：60950-1
• Grade：-
• Qualification：-
