CS-312.500MCC-T

Oscillators Overview

The CS-312.500MCC-T is a standard clock oscillator manufactured by TXC Corporation, utilizing Surface Acoustic Wave (SAW) technology. It operates at a frequency of 312.500 MHz with a supply voltage of 2.5 Volts and a frequency tolerance of 100 ppm. The device functions within a temperature range of -10°C to +70°C and features an LVPECL output type. Its physical dimensions are 5.00mm x 3.20mm, packaged in Tape & Reel format.

Oscillators Feature Summary

• Utilizes SAW technology for stable high-frequency generation
• Provides LVPECL output signal compatibility
• Compact surface-mount package design

Oscillators Applications

• High-speed digital communication systems
• Data transmission equipment requiring precise clocking
• Network infrastructure components

Oscillators Procurement Notes

Verify the specific operating temperature range (-10°C to +70°C) against application requirements. Confirm the 2.5V supply voltage compatibility with target circuitry. Ensure LVPECL output logic levels match downstream receiver inputs. Check packaging specifications for Tape & Reel handling procedures during assembly.

Oscillators Selection Notes

Select this component when a 312.5 MHz reference is required with LVPECL outputs. Consider the 100 ppm tolerance limit for system timing budgets. Evaluate the -10°C to +70°C industrial temperature range suitability. Compare physical footprint constraints against available PCB space.

Oscillators Part Context

This part belongs to the TXC Corporation CS series of standard clock oscillators. It represents a SAW-based solution distinct from crystal or ceramic alternatives. The model designation indicates specific frequency, voltage, and output configuration parameters defined by the manufacturer.

Oscillators Replacement Considerations

BS-312.500MCC-T is listed as a related variant with identical frequency and output type but potentially different electrical characteristics. Verify datasheet specifications for both parts before substitution.
