CS06752-32M

Overview

The CS06752-32M is a surface-mount quartz crystal manufactured by NDK. It operates at a fundamental frequency of 32 MHz with a frequency tolerance of ±10 ppm and stability of ±24 ppm. The component features an 8 pF load capacitance and an equivalent series resistance (ESR) of 100 Ohms. Designed for base mode operation, it supports a temperature range of -10°C to +70°C. The package is a 4-SMD, no-lead configuration measuring 3.2 mm x 2.5 mm.

Feature Summary

• Surface-mount design in a compact 4-SMD no-lead package
• High mechanical robustness suitable for environments with vibration and shock
• Fundamental oscillation mode ensuring stable timing performance

Applications

• Advanced Driver Assistance Systems (ADAS)
• Automotive sensor modules
• Camera interface circuits
• Vehicle navigation systems

Procurement Notes

Verify the specific package dimensions against official datasheets, as external listings may vary. Confirm that the operating temperature range meets the thermal requirements of the target application environment. Ensure compatibility with the circuit's load capacitance specifications before integration.

Selection Notes

Select this component for applications requiring high mechanical durability in automotive contexts. The 32 MHz frequency is suitable for clock generation in processing units. Verify that the 100 Ohm ESR aligns with the oscillator circuit design constraints.

Part Context

This part belongs to NDK's portfolio of crystals engineered for automotive electronics. Unlike standard consumer components, these elements are designed to withstand harsh conditions typical in vehicle environments, including significant physical stress and temperature fluctuations.

Replacement Considerations

No public substitute part numbers are confirmed in the provided documentation.
