Product Detailed Parameters
- Description：CRYSTAL 48.0000MHZ 10PF SMD
- Series：NX1210AB
- Mfr：NDK (NIHON DEMPA KOGYO CO., LTD)
- Package：Tape & Reel (TR),Cut Tape (CT)
- Type：MHz Crystal
- Frequency：48 MHz
- Frequency Stability：-
- Frequency Tolerance：-
- Load Capacitance：10pF
- ESR (Equivalent Series Resistance)：60 Ohms
- Operating Mode：Fundamental
- Operating Temperature：-30°C ~ 85°C
- Ratings：-
- Mounting Type：Surface Mount
- Package / Case：4-SMD, No Lead
- Supplier Device Package：-
- Size / Dimension：0.047" L x 0.039" W (1.20mm x 1.00mm)
- Height - Seated (Max)：0.012" (0.30mm)
Download product information
Overview
The CS10192-48M is a 48 MHz fundamental mode crystal resonator manufactured by NDK. It features a frequency tolerance of ±15 ppm and a frequency stability of ±30 ppm across the operating temperature range. The component has a load capacitance of 10 pF and an equivalent series resistance (ESR) of 60 Ohms maximum. It is housed in a compact 4-SMD, No Lead package with dimensions of 3.20mm x 2.50mm and a maximum height of 0.60mm. The device operates within a temperature range of -10°C to +70°C and is moisture sensitive level 1.
Feature Summary
- Fundamental resonance mode operation for stable frequency generation
- Compact surface-mount design suitable for space-constrained PCB layouts
- Low equivalent series resistance facilitating reliable oscillator circuit startup
Applications
- Bluetooth Low Energy (BLE) modules requiring precise clock sources
- Zigbee and Sub-GHz wireless communication devices
- Portable consumer electronics and wearable devices
Procurement Notes
Verify the specific load capacitance requirement of your oscillator circuit against the 10pF specification of this part. Ensure the application temperature range falls within the -10°C to +70°C operational limits defined by the manufacturer. Confirm that the 60 Ohm ESR maximum aligns with your design's drive level constraints to prevent overdriving the crystal element.
Selection Notes
Select this component when a 48 MHz clock signal is required for wireless protocols such as BLE or Zigbee. It serves as a direct replacement for other NDK NX3225SA series crystals with similar electrical parameters. Consider the 10pF load capacitance carefully; mismatched values can cause frequency drift. This model is appropriate for commercial grade applications where the -10°C to +70°C temperature range is sufficient.
Part Context
This part belongs to the NX3225SA series from NDK, designed specifically for low-power wireless applications. It is commonly referenced in TI CC13xx/CC26xx reference designs. The 3.2x2.5mm package size balances miniaturization with mechanical robustness for surface mount assembly processes.
Replacement Considerations
CS05517-48M: Different package size (2.0x1.6mm) and load capacitance (7pF).
FAQ
What is the maximum Equivalent Series Resistance (ESR) for this crystal?
The maximum ESR is specified as 60 Ohms.
Is this crystal suitable for industrial temperature ranges?
No, the operating temperature range is limited to -10°C to +70°C, which is commercial grade.
