CS12925-76.8M

Overview

The CS12925-76.8M is a surface-mount crystal manufactured by NDK (NIHON DEMPA KOGYO CO., LTD). It operates at a frequency of 76.8 MHz with a load capacitance of 9.9 pF and a frequency tolerance of ±17 ppm. The component utilizes a 4-SMD, No Lead package with dimensions of 0.047 inches in length by 0.039 inches in width.

Feature Summary

• Surface-mount design for automated assembly
• High-frequency operation capability
• Lead-free construction compliant with environmental directives

Applications

• General electronic circuit timing
• Embedded system clock generation
• Consumer electronics signal processing

Procurement Notes

Verify the specific datasheet STD-CSR-1 or series-specific documentation to confirm exact ESR values and stability parameters not listed in general summaries. Ensure the 9.9pF load capacitance matches the target circuit design requirements before integration.

Selection Notes

Select this component when a compact 4-SMD footprint is required for high-frequency applications. The 76.8 MHz frequency is suitable for digital communication interfaces. Verify that the ±17 ppm tolerance aligns with the system's clock accuracy specifications.

Part Context

This part belongs to the NDK crystal family designed for surface-mount technology. It provides stable oscillation for digital circuits requiring precise timing references in space-constrained environments.

Replacement Considerations

Cross-reference with other 76.8 MHz crystals in the 4-SMD package from NDK or alternative manufacturers. Ensure equivalent load capacitance and frequency tolerance are maintained.
