CS16697-25M

Overview

The CS16697-25M is a MHz crystal manufactured by NDK (NIHON DEMPA KOGYO CO., LTD). It operates at a frequency of 25 MHz with a frequency tolerance of ±10ppm and stability of ±40ppm. The component features a load capacitance of 16pF and utilizes a 4-SMD, No Lead package with dimensions of 3.20mm x 2.50mm. It supports surface mount installation and functions in the fundamental mode.

Feature Summary

• Surface mount design for automated assembly
• Fundamental mode operation for stable oscillation
• RoHS3 compliant construction

Applications

• General electronic circuit timing
• Microcontroller clock sources
• Communication device signal generation

Procurement Notes

Verify the specific ordering suffix against the manufacturer's official datasheet to ensure correct frequency tolerance and packaging configuration. Confirm that the selected variant matches the required load capacitance and frequency stability specifications for the target application environment. Cross-reference part numbers with authorized distributors to avoid counterfeit components.

Selection Notes

Select this component when a 25 MHz fundamental mode crystal with 16pF load capacitance is required. Ensure the PCB layout accommodates the 3.20mm x 2.50mm footprint. Verify that the operating temperature range meets the system requirements and that the ESR characteristics are compatible with the oscillator circuit design.

Part Context

This component belongs to the NDK crystal product line, designed for surface mount applications. It provides a reliable frequency reference for digital circuits. The series offers various frequency options within the same physical package to simplify inventory management for common clocking needs in consumer and industrial electronics.

Replacement Considerations

Consult the official NDK replacement guide for direct substitutes. Verify equivalent parameters such as frequency, load capacitance, and package dimensions before substitution.
