CS32-F2525CQ18-14.31818M-TR

Crystals Overview

The CS32-F2525CQ18-14.31818M-TR is a parallel fundamental quartz crystal manufactured by Transko Electronics, Inc. It operates at a nominal frequency of 14.31818 MHz with a frequency tolerance of ±25 ppm. The component features a load capacitance of 18 pF and a maximum series resistance of 80 Ohms. It utilizes a surface-mount ceramic package measuring 3.2 x 2.5 x 0.6 mm with four pins. The device is RoHS compliant and supplied in tape and reel packaging.

Crystals Feature Summary

• Parallel fundamental quartz crystal design for stable oscillation
• Miniature ceramic surface-mount package suitable for reflow soldering
• RoHS compliant construction for environmental safety

Crystals Applications

• General purpose clock generation circuits
• Microcontroller oscillator inputs
• Communication module timing references

Crystals Procurement Notes

Verify the specific suffix codes against the manufacturer's official part numbering guide to ensure exact frequency, tolerance, and load capacitance alignment. Confirm that the 14.31818 MHz specification matches the target circuit requirements precisely. Check for any updated compliance certifications or package dimension revisions in the latest datasheet before finalizing procurement orders.

Crystals Selection Notes

Select this component when a standard 14.31818 MHz reference is required for digital logic interfaces. Ensure the driving circuit can support the specified 80 Ohm series resistance limit. Verify that the 18 pF load capacitance matches the oscillator circuit's input capacitance requirements to achieve accurate frequency performance without additional trimming.

Crystals Part Context

This part belongs to the CS32 family of miniature ceramic SMD crystals from Transko Electronics. The family offers various frequencies and tolerances within a compact footprint. This specific variant targets applications requiring the common 14.31818 MHz frequency point often used in baud rate generation and legacy serial communication standards.

Crystals Replacement Considerations

Transko offers other CS32 variants with different frequencies or tolerances as potential substitutes if specifications differ. Cross-reference with competitor models such as Epson VG-1201CA equivalents only if form-factor compatibility is confirmed.
