CS63A-F3050GK18-24.000M

Crystals Overview

The CS63A-F3050GK18-24.000M is a surface-mount crystal oscillator manufactured by Transko Electronics, Inc. It operates at a nominal frequency of 24 MHz with a stability tolerance of ±30 ppm. The component features an 18 pF load capacitance and a maximum series resistance of 40 Ohms. It is housed in a compact 4-SMD, No Lead package, designed for integration into electronic circuits requiring precise timing signals.

Crystals Feature Summary

• Provides stable 24 MHz oscillation with ±30 ppm frequency tolerance
• Designed for surface-mount assembly using a leadless four-terminal package
• Optimized for low impedance applications with 40 Ohm maximum series resistance

Crystals Applications

• Digital clock signal generation in microcontroller systems
• Synchronization sources for communication interface circuits
• Timing references in consumer electronics devices

Crystals Procurement Notes

Verify the specific ordering suffix to ensure compatibility with required load capacitance and frequency tolerance specifications. Confirm that the package dimensions align with the target PCB footprint. Request the manufacturer datasheet to validate electrical characteristics against system requirements before finalizing procurement.

Crystals Selection Notes

Select this component when a 24 MHz reference is required with moderate stability needs. Ensure the circuit design accommodates the specified 18 pF load capacitance to maintain accurate frequency output. Evaluate the 40 Ohm series resistance limit to confirm it meets the drive level constraints of the host oscillator circuit.

Crystals Part Context

This part belongs to the CS63A series of ceramic SMD crystals from Transko Electronics. The series offers various frequency options in a standardized small outline package format. These components are engineered for high reliability in mass-produced electronic assemblies where consistent timing performance is critical.

Crystals Replacement Considerations

Cross-reference with other 24 MHz SMD crystals offering ±30 ppm stability and 18 pF load capacitance. Verify pinout compatibility and physical dimensions to ensure direct replacement without PCB modification.
