CS63B-F3050CQ16-16.000M-TR

Crystals Overview

The CS63B-F3050CQ16-16.000M-TR is a parallel fundamental quartz crystal manufactured by Transko Electronics, Inc. It operates at a nominal frequency of 16.000 MHz with a frequency tolerance of ±30 ppm and a load capacitance of 16 pF. The component features a maximum series resistance of 40 Ohms and is housed in a compact surface-mount package measuring 2.0 mm x 1.2 mm x 0.6 mm. Designed for standard operating temperatures ranging from 0°C to +70°C, it utilizes a ceramic construction suitable for reflow soldering processes.

Crystals Feature Summary

• Parallel fundamental quartz crystal operation
• Compact miniature surface-mount package
• RoHS compliant manufacturing

Crystals Applications

• General purpose clock signal generation
• Microcontroller oscillator circuits
• Communication device timing references

Crystals Procurement Notes

Verify the specific load capacitance requirement of your circuit design against the component's 16 pF specification to ensure accurate frequency performance. Confirm that the operating temperature range of 0°C to +70°C aligns with your application environment. Ensure compatibility with standard surface-mount reflow soldering profiles during assembly planning.

Crystals Selection Notes

Select this component when a precise 16.000 MHz reference is required in a minimal footprint. Consider the ±30 ppm tolerance for applications where moderate frequency stability is sufficient. Evaluate the 40 Ohm series resistance against your oscillator circuit's drive level requirements to prevent over-driving the crystal.

Crystals Part Context

This part belongs to the CS63B series of miniature SMD crystals from Transko Electronics. These components are designed for high-volume consumer electronics and telecommunications equipment requiring reliable frequency control in space-constrained designs.

Crystals Replacement Considerations

Direct substitutes must match the 16.000 MHz frequency, 16 pF load capacitance, and 2.0x1.2mm package dimensions. Verify equivalent electrical parameters including ±30 ppm tolerance and 40 Ohm max series resistance before integration.
