CS63C-F3050CQ18-12.000M-TR

Crystals Overview

The CS63C-F3050CQ18-12.000M-TR is a surface-mount crystal oscillator manufactured by Transko Electronics, Inc. It operates at a nominal frequency of 12 MHz with a load capacitance of 18 pF and an equivalent series resistance (ESR) of 100 Ohms. The component is housed in a compact 2-SMD, No Lead package designed for automated assembly processes. This device provides stable frequency generation suitable for precision timing applications requiring reliable performance in electronic circuits.

Crystals Feature Summary

• Surface-mount design compatible with standard SMD reflow soldering processes
• Optimized for high-volume manufacturing through leadless package configuration
• Provides precise 12 MHz frequency output for timing synchronization

Crystals Applications

• Automotive hybrid systems
• Electric vehicle powertrain control units
• General industrial timing circuits

Crystals Procurement Notes

Verify the specific operating temperature range and stability specifications against your system requirements before procurement. Confirm that the 18 pF load capacitance matches your circuit design to ensure accurate frequency operation. Ensure compatibility with your PCB footprint and reflow profile standards. Request official datasheets from authorized distributors to validate current production status and quality certifications prior to placing orders.

Crystals Selection Notes

Select this component when a 12 MHz reference signal is required in space-constrained automotive or industrial designs. The 18 pF load capacitance must align with the oscillator circuit's input requirements. Consider the 2-SMD package dimensions for board layout constraints. Evaluate thermal stability needs against the component's specified operating range to guarantee long-term reliability in harsh environments.

Crystals Part Context

This part belongs to Transko's CS63C series of surface-mount crystals. The series is engineered for automotive and industrial applications requiring robust frequency stability. The model designation indicates a 12 MHz frequency, 18 pF load capacitance, and tape-and-reel packaging for efficient automated placement in high-speed manufacturing lines.

Crystals Replacement Considerations

No public confirmed substitute part numbers are available for this specific component.
