CS75-F1010FM15-13.824M-TR

Crystals Overview

The CS75-F1010FM15-13.824M-TR is a miniature ceramic surface-mount crystal oscillator manufactured by Transko Electronics, Inc. It operates at a nominal frequency of 13.824 MHz with a frequency stability and tolerance of ±10ppm. The component features a load capacitance of 15pF and an equivalent series resistance (ESR) of 60 Ohms. It is housed in a compact 4-SMD, No Lead package measuring 7.0 x 5.0 x 1.1mm. The device supports HCMOS output levels within a voltage range of 1.8V to 3.3V and is available in tape and reel packaging for automated assembly.

Crystals Feature Summary

• Miniature ceramic construction designed for space-constrained surface-mount applications
• HCMOS output compatibility supporting low-voltage logic systems
• High frequency stability ensuring precise timing performance

Crystals Applications

• Clock generation for microprocessors and microcontrollers
• Timing reference for communication interfaces
• Synchronization circuits in consumer electronics

Crystals Procurement Notes

Verify the specific suffix TR indicates tape and reel packaging configuration when sourcing. Confirm that the 15pF load capacitance matches the target circuit design requirements. Ensure the 4-SMD no-lead package dimensions align with PCB footprint specifications. Check RoHS compliance status if environmental regulations apply to the end product.

Crystals Selection Notes

Select this component when a stable 13.824 MHz reference is required for low-voltage digital systems. The ±10ppm tolerance suits applications demanding moderate precision. Consider the 60 Ohm ESR value for oscillator circuit loading calculations. The 7x5mm package offers a balance between size and thermal performance compared to smaller alternatives.

Crystals Part Context

This part belongs to the CS75 series of miniature ceramic SMD crystals from Transko Electronics. The series covers frequencies from 1MHz to 137MHz in various SMD packages ranging from 2.0x1.6mm to 7.0x5.0mm. The CS75 model specifically denotes the 7.0x5.0mm form factor suitable for general-purpose timing applications.

Crystals Replacement Considerations

Direct substitutes include other 13.824 MHz crystals with identical 15pF load capacitance and similar ESR values. Verify package compatibility before substitution. Cross-reference with other manufacturers offering 4-SMD no-lead ceramic resonators meeting the same electrical specifications.
