CS75-F1010HJ12-20.736M-TR

Crystals Overview

The CS75-F1010HJ12-20.736M-TR is a miniature ceramic surface-mount crystal oscillator manufactured by Transko Electronics, Inc. It operates at a fundamental frequency of 20.736 MHz with a load capacitance of 12 pF and an equivalent series resistance of 40 Ohms. The component features a tolerance of ±10 ppm and is housed in a 4-SMD, No Lead package measuring 7.0 mm x 5.0 mm x 1.1 mm. It complies with RoHS standards and is lead-free.

Crystals Feature Summary

• Miniature ceramic construction for space-constrained designs
• Surface-mount technology compatible with automated assembly
• Lead-free and RoHS compliant manufacturing

Crystals Applications

• General-purpose clock generation in digital circuits
• Microcontroller system timing references
• Communication interface synchronization

Crystals Procurement Notes

Verify the complete part number including suffixes to ensure correct frequency and tolerance specifications. Confirm RoHS compliance status if required by regulatory standards. Check manufacturer datasheets for soldering profile recommendations to prevent thermal damage during reflow processes. Ensure storage conditions meet humidity sensitivity levels before assembly.

Crystals Selection Notes

Select this component when a 20.736 MHz reference signal is required in a compact 7x5mm footprint. Consider the 12 pF load capacitance requirement for circuit design compatibility. Evaluate the 40 Ohm ESR against driver capability requirements. Verify that the ±10 ppm stability meets the application's timing accuracy needs.

Crystals Part Context

This part belongs to the CS75 series of miniature ceramic SMD crystals from Transko Electronics. The series offers various frequencies in a standardized 7.0 x 5.0 x 1.1 mm package. The CS75 line is designed for high-volume surface-mount applications requiring reliable frequency control in consumer and industrial electronics.

Crystals Replacement Considerations

Cross-reference with other 20.736 MHz crystals in 4-SMD packages having 12 pF load capacitance. Verify mechanical dimensions and pin configuration compatibility. Ensure electrical parameters such as ESR and stability match or exceed original requirements.
