CSAB1030A-R22M

$0.83

Description：FIX IND 0.22UH 32A 1.5MOHM SMD
Series：CSAB1030A
Mfr：CODACA
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:0d2d9f1905b1 Category: Fixed Inductors Brand: CODACA

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

CSAB1030A-R22M is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists CODACA. Its product description is FIX IND 0.22UH 32A 1.5MOHM SMD. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for CSAB1030A-R22M

Description：FIX IND 0.22UH 32A 1.5MOHM SMD
Series：CSAB1030A
Mfr：CODACA
Package：Tape & Reel (TR),Cut Tape (CT)
Type：Molded
Material - Core：Alloy Powder
Inductance：220 nH
Tolerance：±20%
Current Rating (Amps)：32 A
Current - Saturation (Isat)：38A
Shielding：Shielded
DC Resistance (DCR)：1.5mOhm Max
Q @ Freq：-
Frequency - Self Resonant：-
Ratings：AEC-Q200
Operating Temperature：-40°C ~ 125°C
Inductance Frequency - Test：100 kHz
Mounting Type：Surface Mount
Package / Case：Nonstandard
Supplier Device Package：-
Size / Dimension：0.453" L x 0.394" W (11.50mm x 10.00mm)
Height - Seated (Max)：0.118" (3.00mm)
Features：-

Fixed Inductors datasheet and documents for CSAB1030A-R22M

CSAB1030A-R22M

Fixed Inductors Overview

The CSAB1030A-R22M is a shielded molded power inductor from the CODACA CSAB series, designed for surface-mount applications. It features a carbonyl powder core and offers an inductance of 22 µH with a tolerance of ±20%. The component supports a maximum DC current of 4.5 A and reaches saturation at 6.5 A. Its maximum DC resistance is 18 mΩ, and it operates within a temperature range of -40°C to +125°C. The package dimensions are 10.0 mm x 7.3 mm x 3.0 mm.

Fixed Inductors Feature Summary

Shielded construction minimizes electromagnetic interference
Carbonyl powder core provides high saturation performance
Molded design ensures mechanical stability

Fixed Inductors Applications

Automotive electronics systems
Industrial control circuits
Power supply modules

Fixed Inductors Procurement Notes

Verify the specific part number against official manufacturer documentation to confirm electrical parameters and physical dimensions. Ensure that the selected variant matches the required inductance value and current ratings for the target application circuit. Cross-reference datasheet specifications regarding thermal performance and mounting requirements before finalizing procurement decisions.

Fixed Inductors Selection Notes

Select this component based on its 22 µH inductance and 4.5 A continuous current rating. Consider the 18 mΩ DC resistance for efficiency calculations. Verify compatibility with surface-mount assembly processes and ensure the operating temperature range meets environmental conditions. Confirm package size constraints fit the PCB layout requirements.

Fixed Inductors Part Context

This fixed inductor belongs to the CSAB series of high saturation molding power chokes manufactured by CODACA Electronic Co., Ltd. The series utilizes proprietary core materials to achieve fast customization capabilities. The company holds ISO9001, IATF16949, and CNAS certifications, supporting reliable production for automotive and industrial markets.
