CSBA1060-8R2M

Fixed Inductors Overview

The CSBA1060-8R2M is a shielded wirewound power inductor manufactured by CODACA, designed for surface-mount applications. It features a compact 2-SMD package with dimensions of 10.0mm x 6.0mm x 6.0mm. The component provides an inductance of 8.2 µH with a tolerance of ±20%. It supports a maximum rated current of 3.5 A and a saturation current of 4.5 A. The DC resistance is specified at a maximum of 37 mΩ. Operating reliably within a temperature range of -40°C to +125°C, it utilizes a carbonyl iron powder core material suitable for high-current power supply circuits.

Fixed Inductors Feature Summary

• Shielded wirewound construction minimizes electromagnetic interference
• Low DC resistance design reduces power loss
• Soft saturation characteristics maintain performance under load

Fixed Inductors Applications

• Point-of-load voltage regulation modules
• High-current DC-DC converter stages
• Server and workstation power distribution networks

Fixed Inductors Procurement Notes

Verify the specific ordering suffix against the manufacturer's official datasheet to ensure correct packaging configuration. Confirm that the requested quantity aligns with standard reel sizes. Cross-reference the part number with authorized distributor catalogs to validate authenticity and traceability before finalizing procurement orders.

Fixed Inductors Selection Notes

Select this component when circuit requirements demand high saturation current alongside low impedance. The 8.2 µH value suits intermediate frequency switching applications. Ensure the PCB footprint matches the 10x6 mm package dimensions. Verify thermal management capabilities as the device operates up to 125°C without derating issues.

Fixed Inductors Part Context

This model belongs to the CSBA series of high-current power inductors from CODACA. The series emphasizes robust magnetic shielding and low loss characteristics. It complements other components in the manufacturer's portfolio designed for demanding power electronics environments requiring reliable energy storage.

Fixed Inductors Replacement Considerations

Consult the official substitution list for equivalent models with matching electrical parameters. Verify pin compatibility and thermal performance before replacing the original component in existing designs.
