CSBC222-1802A001C1AF

Headers, Receptacles, Female Sockets Overview

The CSBC222-1802A001C1AF is a female header PCB receptacle from the Greenconn CSBC222 series, designed for board-to-board applications. It features a pick-and-place compatible construction suitable for automated assembly processes. The component is rated for a current of 0.5 Amps and offers a minimum insulation resistance of 1000 MΩ. Its dielectric withstanding voltage capacity is specified at 300 VAC, while the maximum contact resistance is limited to 20 mΩ.

Headers, Receptacles, Female Sockets Feature Summary

• Designed as a female header PCB receptacle for direct board-to-board interconnection
• Constructed with pick-and-place compatibility to support automated surface-mount assembly
• Engineered to provide reliable electrical performance within specified voltage and current limits

Headers, Receptacles, Female Sockets Applications

• Board-to-board connections in electronic assemblies
• Automated pick-and-place manufacturing environments
• General PCB receptacle applications requiring female socket interfaces

Headers, Receptacles, Female Sockets Procurement Notes

Verify that the specific part number matches the required pin count and pitch specifications for your design. Confirm that the manufacturer's standard lead time aligns with your production schedule. Ensure that the electrical ratings, including the 0.5 Amp current limit and 300 VAC dielectric strength, meet the operational requirements of your circuit. Check for any specific handling instructions related to its pick-and-place construction.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when a female header PCB receptacle is required for board-to-board stacking. Consider the CSBC222 series if pick-and-place functionality is necessary for high-volume automated assembly. Verify that the 0.5 Amp current rating and 1000 MΩ insulation resistance are sufficient for the target application. Compare against other Greenconn series options if different pitch or contact configurations are needed.

Headers, Receptacles, Female Sockets Part Context

This component belongs to the Greenconn CSBC222 series, which focuses on board-to-board connectivity solutions. The series includes various female header PCB receptacles designed for different pin counts and configurations. Greenconn manufactures these connectors to support automated assembly processes, ensuring consistency and reliability in electronic interconnections across multiple product lines.

Headers, Receptacles, Female Sockets Replacement Considerations

Direct substitutes within the same series include CSBC222-3002A001C1AF and CSBC222-3402A001C1AF. These parts share the same female header PCB receptacle style and pick-and-place features. Verify that the pin count and physical dimensions match the original design before substitution.
