CSEC202-0602A001R1AF

Headers, Receptacles, Female Sockets Overview

The CSEC202-0602A001R1AF is a dual-row, surface-mount vertical female header manufactured by Greenconn. It features 12 positions arranged in a 2x6 configuration with a 1.27mm (0.050 inch) pitch. The connector utilizes phosphor bronze contacts with gold plating to ensure reliable signal transmission and low contact resistance. Designed for high-temperature environments, it operates within a temperature range of -40°C to +105°C. The unit supports a current rating of 1A and withstands dielectric voltages up to 300VAC. It meets UL94V-0 flammability standards for the thermoplastic housing.

Headers, Receptacles, Female Sockets Feature Summary

• Dual-row surface mount vertical design for compact PCB integration
• Gold-plated phosphor bronze contacts for durability and conductivity
• High-temperature resistant thermoplastic housing compliant with UL94V-0

Headers, Receptacles, Female Sockets Applications

• Consumer electronics internal connections
• Industrial control board interconnects
• Automotive electronic module interfaces

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific suffix R1AF against official Greenconn documentation to confirm contact plating specifications and material composition. Ensure the ordering part number matches the required 12-position count and dual-row configuration. Cross-reference the datasheet for precise mechanical dimensions and soldering profile requirements to guarantee compatibility with automated assembly processes.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when a low-profile, dual-row female header is required for surface-mount assembly. The 1.27mm pitch suits applications needing dense pin arrangements without excessive board space consumption. Consider the 1A current rating and 300V dielectric strength for standard signal and low-power data lines. Verify that the operating temperature range aligns with the environmental conditions of the final product assembly.

Headers, Receptacles, Female Sockets Part Context

This model belongs to the CSEC202 series of Greenconn connectors, which are characterized by their SMT vertical female header construction. The series offers various position counts and row configurations to accommodate different circuit density needs. Components in this family typically share similar mechanical footprints and mating characteristics, facilitating standardized design practices across multiple product lines.

Headers, Receptacles, Female Sockets Replacement Considerations

Direct substitutes include other Greenconn models within the CSEC202 series with identical pitch and row counts, such as CSEC202-0802A001C1AC or CSEC202-0502A001R1AC, provided the pin count matches the application requirement. Verify that alternative parts maintain the same surface-mount orientation and voltage ratings before implementation.
