CSHB0515-3R3M

Fixed Inductors Overview

The CSHB0515-3R3M is a fixed shielded molded inductor from CODACA with an inductance of 3.3 µH and a maximum DC resistance of 67.5 mΩ. It supports a rated current of 5.3 A and utilizes a 2-SMD surface-mount package.

Fixed Inductors Feature Summary

• Features a magnetic shielded structure for excellent resistance to electromagnetic interference (EMI).
• Utilizes a composite structure design to achieve ultra-low buzz noise.
• Engineered for low loss, high efficiency, and suitability across wide application frequencies.

Fixed Inductors Applications

• GaN-based power systems
• High-current power supply circuits
• Space-constrained electronic designs

Fixed Inductors Procurement Notes

Verify the specific part number against official CODACA documentation to confirm electrical parameters and physical dimensions. Ensure compatibility with existing PCB footprints and thermal management requirements before integration into the final assembly.

Fixed Inductors Selection Notes

Select this component based on its 3.3 µH inductance value and 5.3 A current rating. The shielded molded construction makes it suitable for applications requiring EMI suppression and low acoustic noise within compact form factors.

Fixed Inductors Part Context

This component belongs to the CSHB series of molding power chokes manufactured by Shenzhen Codaca Electronic Co., Ltd. The series is characterized by robust materials and advanced manufacturing techniques designed for rigorous operating conditions and long-lasting performance.

Fixed Inductors Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided source data. Verify pinout and parameter equivalence with alternative manufacturers if sourcing changes are required.
