CSHC106-0502A004C1AC

Headers, Receptacles, Female Sockets Overview

The Greenconn CSHC106-0502A004C1AC is a female header PCB receptacle from the CSHC106 series. It features a 5-position, single-row configuration with a 0.100 inch (2.54mm) pitch. Designed for surface mount installation, it utilizes phosphor bronze contacts with gold plating to ensure reliable signal transmission. The connector supports a rated current of 3A and a voltage of 250VAC/DC. Constructed with black liquid crystal polymer insulation rated UL94 V-0, it operates within a temperature range of -40°C to 105°C.

Headers, Receptacles, Female Sockets Feature Summary

• Surface mount design for automated PCB assembly
• Gold-plated phosphor bronze contacts for corrosion resistance
• High-temperature LCP insulation material for stability

Headers, Receptacles, Female Sockets Applications

• Industrial control systems
• Automotive electronics
• Telecommunications equipment

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific pin count matches the '05' designation in the part number to ensure correct positioning. Confirm surface mount compatibility with your PCB footprint. Check RoHS compliance status if required by your manufacturing standards. Ensure the operating temperature range aligns with your environmental requirements.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when a 5-position female header is required for board-to-board or cable connections. The 2.54mm pitch is standard for many industrial interfaces. Consider the 3A current rating for power distribution needs. Verify that the surface mount termination method suits your production capabilities.

Headers, Receptacles, Female Sockets Part Context

This part belongs to the Greenconn CSHC106 series of rectangular connectors. The series offers various position counts and mounting styles. It is designed for general interconnect applications requiring reliable performance in demanding environments. The manufacturer provides consistent specifications across the series for easy integration.

Headers, Receptacles, Female Sockets Replacement Considerations

Direct substitutes must match the 5-position count, 2.54mm pitch, and surface mount style. Verify identical electrical ratings and insulation materials. Cross-reference mechanical dimensions to ensure PCB footprint compatibility. Consult distributor databases for equivalent parts from other manufacturers.
