CSHC206-0602A006R1AC

Headers, Receptacles, Female Sockets Overview

The Greenconn CSHC206-0602A006R1AC is a female header PCB receptacle from the CSHC206 series. It features a single row with six positions and a 0.100" (2.54mm) pitch. Designed for surface mount installation, it utilizes phosphor bronze contacts with gold plating. The connector supports a rated current of 3A and a voltage of 250V AC/DC. Constructed with black liquid crystal polymer insulation rated UL94 V-0, it operates within a temperature range of -40°C to 105°C.

Headers, Receptacles, Female Sockets Feature Summary

• Surface mount design for automated PCB assembly
• Gold-plated phosphor bronze contacts for reliable signal transmission
• High-temperature resistant LCP insulation material

Headers, Receptacles, Female Sockets Applications

• General electronic circuit interconnections
• Board-to-board connections in consumer electronics
• Industrial control system modules

Headers, Receptacles, Female Sockets Procurement Notes

Verify that the specific part number matches the required six-position configuration and surface mount orientation. Confirm compatibility with standard reflow soldering profiles for lead-free processes. Ensure the selected variant aligns with the intended operating temperature range and current rating requirements for the target application environment.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when a low-profile, single-row female header is required for surface mounting. It is suitable for applications needing robust electrical performance at 3A and 250V. Consider the 2.54mm pitch for standard spacing constraints and the black LCP housing for high-temperature stability during soldering and operation.

Headers, Receptacles, Female Sockets Part Context

This component belongs to the Greenconn CSHC206 series of rectangular connectors. The series offers various pin counts and configurations for different board space limitations. As a female header, it provides a secure mating interface for corresponding male pins or cables, ensuring stable mechanical and electrical connections in compact electronic assemblies.

Headers, Receptacles, Female Sockets Replacement Considerations

Cross-reference with other Greenconn CSHC206 variants for different pin counts. Verify that alternative suppliers offer identical 2.54mm pitch and surface mount specifications. Ensure substitute parts maintain the same UL94 V-0 flammability rating and thermal resistance capabilities.
