CT-212.500MCC-T

Oscillators Overview

The CT-212.500MCC-T is a Surface Mount SAW Oscillator manufactured by TXC Corporation, operating at a nominal frequency of 212.5 MHz. It utilizes LVDS output format and requires a nominal supply voltage of 2.5 V. The device features a frequency stability of +/-100 ppm and includes an enable/disable control function. It is housed in a compact 6-SMD, No Lead package with dimensions of 5 mm x 3.2 mm. The operational temperature range extends from -40°C to +85°C, ensuring reliability in various electronic applications.

Oscillators Feature Summary

• Integrated enable and disable control functionality for power management
• Low Emission Differential Signaling (LVDS) output format
• Surface mount design in a compact 6-SMD no lead package

Oscillators Applications

• High-speed data communication interfaces
• Network synchronization equipment
• Test and measurement instrumentation

Oscillators Procurement Notes

Verify the specific ordering suffix against the manufacturer's official datasheet to confirm pinout compatibility and electrical specifications. Ensure that the selected variant matches the required supply voltage and output format for the target circuit design. Cross-reference the part number with authorized distributors to confirm current availability and authenticity before procurement.

Oscillators Selection Notes

Select this component when a precise 212.5 MHz clock signal with LVDS outputs is required in a space-constrained environment. The integrated enable/disable feature allows for dynamic power control. Consider the +/-100 ppm stability specification relative to system timing requirements. Verify that the 2.5 V supply voltage aligns with the available power rails in the application design.

Oscillators Part Context

This oscillator belongs to the CT series of surface mount SAW devices from TXC Corporation. These components are designed for high-frequency applications requiring stable clock signals. The series offers various frequency options and packaging configurations to suit different industrial and commercial electronics needs.

Oscillators Replacement Considerations

Direct substitutes must match the 212.5 MHz frequency, LVDS output, 2.5V supply, and 5x3.2mm SMD package. Verify pin compatibility and electrical parameters before substitution.
