CTAC0805F-6N8K is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Central Technologies. Its product description is SMD AIR CORE INDUCTOR. Review the specifications below when checking this part for your BOM.
Fixed Inductors specifications for CTAC0805F-6N8K
- Description：SMD AIR CORE INDUCTOR
- Series：ctac0805f
- Mfr：Central Technologies
- Package：Tape & Reel (TR)
- Type：Wirewound
- Material - Core：-
- Inductance：6.8 nH
- Tolerance：±10%
- Current Rating (Amps)：-
- Current - Saturation (Isat)：-
- Shielding：-
- DC Resistance (DCR)：4.5mOhm
- Q @ Freq：-
- Frequency - Self Resonant：3GHz
- Ratings：-
- Operating Temperature：-25°C ~ 85°C
- Inductance Frequency - Test：-
- Mounting Type：Surface Mount
- Package / Case：-
- Supplier Device Package：-
- Size / Dimension：-
- Height - Seated (Max)：-
- Features：-
Fixed Inductors datasheet and documents for CTAC0805F-6N8K
Fixed Inductors Overview
The CTAC0805F-6N8K is a surface-mount air core inductor manufactured by Central Technologies. It features a nominal inductance of 6.8 nH and a maximum DC resistance of 4.5 mOhm. The component utilizes a wirewound construction within an 0805 package outline, designed for high-frequency applications requiring low parasitic effects.
Fixed Inductors Feature Summary
- Air core construction minimizes magnetic saturation and hysteresis losses
- Wirewound design ensures stable inductance characteristics
- Surface-mount format facilitates automated PCB assembly
Fixed Inductors Applications
- RF matching networks
- High-speed signal filtering
- Impedance matching circuits
Fixed Inductors Procurement Notes
Verify the specific manufacturer datasheet for the CTAC0805F-6N8K to confirm exact electrical tolerances and thermal ratings. Ensure that the supplier provides original documentation from Central Technologies to validate authenticity. Cross-reference the part number with official distribution channels to avoid counterfeit components. Confirm packaging specifications align with production requirements before finalizing orders.
Fixed Inductors Selection Notes
Select this component when circuit designs demand minimal inductance values below 10 nH. The air core structure is suitable for environments where magnetic interference must be avoided. Evaluate the 0805 footprint against available board space constraints. Consider the low DC resistance for power efficiency in high-current RF paths compared to higher-inductance alternatives.
Fixed Inductors Part Context
Central Technologies produces a wide range of passive components, including various inductor series. The CTAC0805F series represents their line of surface-mount air core inductors. This specific model falls within the standard industrial component catalog used in telecommunications and computing hardware sectors.
Fixed Inductors Replacement Considerations
Consult official substitution lists from Central Technologies for direct equivalents. Verify that any alternative part maintains the same 6.8 nH value and 0805 package dimensions. Ensure compatibility with existing reflow soldering profiles and impedance requirements.
