CTCDRH124F-220M

Fixed Inductors Overview

The CTCDRH124F-220M is a shielded surface-mount power inductor from Central Technologies. It features a nominal inductance of 22 µH with a tolerance of ±20%. The component has a maximum DC resistance of 66 mΩ and a rated current of 2.9 A. It operates within a temperature range of -25°C to +80°C.

Fixed Inductors Feature Summary

• Shielded wirewound construction for reduced electromagnetic interference
• Surface mount design suitable for automated assembly
• RoHS compliant manufacturing process

Fixed Inductors Applications

• Power supplies for VTR equipment
• Office automation equipment
• LCD televisions
• PC notebooks
• Portable communication devices

Fixed Inductors Procurement Notes

Verify the specific suffix 'F' indicates RoHS compliance as documented. Confirm the package dimensions match the required PCB footprint. Ensure the thermal rating aligns with the application environment. Check that the current rating meets the circuit requirements without saturation.

Fixed Inductors Selection Notes

Select this component for applications requiring shielded power inductors in compact form factors. Consider the 2.9 A current rating and low DCR for efficiency. Verify compatibility with SMD reflow processes. Compare against similar series parts if higher current or different inductance values are needed.

Fixed Inductors Part Context

This part belongs to the CTCDRH124 series of shielded power inductors manufactured by Central Technologies. The series offers various inductance values ranging from 10 µH to 1,000 µH. These components are designed for general-purpose power filtering and energy storage in electronic circuits.
