CTCDRH2D11/HPF-6R8N

$0.71

Description：6.8UH SMD SHIELDED POWR INDUCTOR
Series：CTCDRH2D11/HPF
Mfr：Central Technologies
Package：Tape & Reel (TR)

SKU:f3641499c5c8 Category: Fixed Inductors Brand: Central Technologies

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

CTCDRH2D11/HPF-6R8N is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Central Technologies. Its product description is 6.8UH SMD SHIELDED POWR INDUCTOR. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for CTCDRH2D11/HPF-6R8N

Description：6.8UH SMD SHIELDED POWR INDUCTOR
Series：CTCDRH2D11/HPF
Mfr：Central Technologies
Package：Tape & Reel (TR)
Type：-
Material - Core：-
Inductance：6.8 µH
Tolerance：±30%
Current Rating (Amps)：-
Current - Saturation (Isat)：630mA
Shielding：Shielded
DC Resistance (DCR)：371mOhm Max
Q @ Freq：-
Frequency - Self Resonant：-
Ratings：-
Operating Temperature：-40°C ~ 85°C
Inductance Frequency - Test：100 kHz
Mounting Type：Surface Mount
Package / Case：Nonstandard
Supplier Device Package：-
Size / Dimension：0.126" L x 0.126" W (3.20mm x 3.20mm)
Height - Seated (Max)：0.047" (1.20mm)
Features：-

Fixed Inductors datasheet and documents for CTCDRH2D11/HPF-6R8N

CTCDRH2D11/HPF-6R8N

Fixed Inductors Overview

The CTCDRH2D11/HPF-6R8N is a shielded surface-mount power inductor from Central Technologies. It features a nominal inductance of 6.8 µH with a tolerance of ±30%. The component has a maximum DC resistance of 0.23 Ω and a saturation current rating of 0.23 A. It operates within a temperature range of -30 °C to 100 °C.

Fixed Inductors Feature Summary

Shielded magnetic structure for reduced electromagnetic interference
Surface-mount design for automated assembly integration
RoHS compliant construction without lead content

Fixed Inductors Applications

Power supply filtering circuits
DC-DC converter energy storage
General purpose power inductor applications

Fixed Inductors Procurement Notes

Verify the specific suffix 'HPF' against official Central Technologies documentation to confirm it denotes the correct high-performance variant or packaging specification. Ensure the part number matches the exact electrical requirements for shielding and current ratings before procurement.

Fixed Inductors Selection Notes

Select this component for applications requiring a compact, shielded power inductor with a 6.8 µH value. Consider the 0.23 A saturation current limit when designing circuits to prevent performance degradation under load conditions.

Fixed Inductors Part Context

This part belongs to the CTCDRH2D11 series of shielded power inductors manufactured by Central Technologies. The series offers various inductance values optimized for surface-mount technology in electronic power systems.
