CTDR0904F-510

Common Mode Chokes Overview

The CTDR0904F-510 is a surface-mount common mode choke manufactured by Central Technologies. It features two lines with an inductance of 51 µH at 100 kHz and an impedance of 1.5 kOhms at 100 MHz. The component supports a maximum rated current of 500 mA and has a DC resistance (DCR) of 300 mOhms. Physical dimensions are 7.3 × 5.4 × 4.7 mm, and it operates within a temperature range of -40°C to +105°C.

Common Mode Chokes Feature Summary

• Provides common mode noise suppression for data lines
• Designed for surface mount assembly
• Supports dual-line configurations

Common Mode Chokes Applications

• Data line filtering
• Signal integrity protection in electronic circuits

Common Mode Chokes Procurement Notes

Verify the specific part number CTDR0904F-510 against official Central Technologies documentation to confirm electrical parameters such as inductance, impedance, and current ratings. Ensure the package type and operating temperature range match the design requirements before procurement.

Common Mode Chokes Selection Notes

Select this component when designing circuits requiring common mode noise reduction for high-speed data lines. Consider the 500 mA current rating and 51 µH inductance values to ensure compatibility with signal frequencies and power constraints.

Common Mode Chokes Part Context

This component belongs to the CTDR series of data line chokes from Central Technologies. These components are engineered for surface mount applications, offering compact solutions for electromagnetic interference mitigation in modern electronic devices.

Common Mode Chokes Replacement Considerations

Consult official manufacturer substitution lists for verified equivalents. Generic replacements may differ in impedance characteristics or physical dimensions.
