CTEP125HF-7R2

Fixed Inductors Overview

The CTEP125HF-7R2 is a shielded wirewound power inductor from Central Technologies, designed for surface-mount applications. It features an inductance of 7.2 µH with a maximum DC resistance of 13.5 mΩ. The component supports high current handling capabilities, rated at 7.8 A, and operates within a temperature range of -30°C to +100°C. Its compact dimensions are 12.5 × 12.5 × 5.6 mm, making it suitable for space-constrained designs requiring robust magnetic shielding.

Fixed Inductors Feature Summary

• Shielded wirewound construction for reduced electromagnetic interference
• High current handling capability for power supply applications
• Surface-mount design for automated assembly processes

Fixed Inductors Applications

• DC-DC converter output filtering
• Power management circuits
• Industrial control systems

Fixed Inductors Procurement Notes

Verify the specific suffix '7R2' corresponds to the required 7.2 µH inductance value during procurement. Confirm that the RoHS compliance status meets regulatory requirements for your target market. Ensure the surface-mount footprint matches the PCB layout specifications to guarantee proper solder joint integrity and mechanical stability.

Fixed Inductors Selection Notes

Select this component when high current capacity and magnetic shielding are critical for circuit performance. The low DC resistance minimizes power loss and heat generation in high-current paths. Consider the operating temperature range to ensure reliability under varying environmental conditions typical in industrial or automotive environments.

Fixed Inductors Part Context

This part belongs to the CTEP125HF series of fixed inductors manufactured by Central Technologies. The series focuses on providing reliable inductive components for various electronic applications. Central Technologies specializes in inductive components and magnets, serving sectors such as aerospace and general electronics where quality and standard compliance are prioritized.

Fixed Inductors Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Verify compatibility with existing circuit parameters if considering alternative manufacturers.
