CTGSR74BF-180M

Fixed Inductors Overview

The CTGSR74BF-180M is a shielded surface-mount power inductor manufactured by Central Technologies. It features a nominal inductance of 18 µH with a tolerance of ±20%. The component operates within a temperature range of -40°C to +85°C and has a test frequency of 1 kHz. It utilizes a nonstandard rectangular package suitable for automated assembly.

Fixed Inductors Feature Summary

• Shielded construction minimizes electromagnetic interference
• Surface-mount design facilitates automated PCB assembly
• Robust thermal performance across industrial temperature ranges

Fixed Inductors Applications

• DC-DC converter output filtering
• Power supply input stages
• General-purpose power inductor circuits

Fixed Inductors Procurement Notes

Verify the specific suffix 'M' indicates the required 20% tolerance variant. Confirm the operating temperature rating aligns with system requirements. Ensure the surface-mount footprint matches the target PCB layout dimensions before finalizing procurement orders.

Fixed Inductors Selection Notes

Select this component for applications requiring compact shielding and stable inductance values. Consider the 18 µH value and current handling capabilities relative to the circuit load. Evaluate the surface-mount form factor against available board space constraints.

Fixed Inductors Part Context

This part belongs to the CTGSR74BF series of fixed inductors from Central Technologies. The series includes various inductance values tailored for power electronics. The model designation specifies the electrical characteristics and physical packaging style.

Fixed Inductors Replacement Considerations

Cross-reference with other shielded SMD power inductors offering 18 µH ±20% tolerance. Verify compatibility regarding DC resistance, saturation current, and thermal limits. Ensure the replacement maintains the same surface-mount footprint.
