CTMMP1805F-4R7M is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Central Technologies. Its product description is SMD Shielded Power Inductor. Review the specifications below when checking this part for your BOM.
Fixed Inductors specifications for CTMMP1805F-4R7M
- Description：SMD Shielded Power Inductor
- Series：-
- Mfr：Central Technologies
- Package：Bulk
- Type：-
- Material - Core：-
- Inductance：4.7 µH
- Tolerance：±20%
- Current Rating (Amps)：2.8 A
- Current - Saturation (Isat)：-
- Shielding：Shielded
- DC Resistance (DCR)：195mOhm
- Q @ Freq：-
- Frequency - Self Resonant：-
- Ratings：-
- Operating Temperature：-55°C ~ 125°C
- Inductance Frequency - Test：-
- Mounting Type：Surface Mount
- Package / Case：-
- Supplier Device Package：-
- Size / Dimension：0.161" L x 0.181" W (4.10mm x 4.60mm)
- Height - Seated (Max)：0.047" (1.20mm)
- Features：-
Fixed Inductors datasheet and documents for CTMMP1805F-4R7M
Fixed Inductors Overview
The CTMMP1805F-4R7M is a shielded surface-mount power inductor manufactured by Central Technologies. It features a nominal inductance of 4.7 µH with a tolerance of ±20%. The component has a maximum rated current of 2.8 A and a DC resistance of 195 mΩ. It operates within a temperature range of -55°C to +125°C.
Fixed Inductors Feature Summary
- Shielded construction minimizes electromagnetic interference
- Designed for switch-mode power supply applications
- Surface-mount package facilitates automated assembly
Fixed Inductors Applications
- Switch-mode power supplies operating at 500 kHz to 1 MHz
- General purpose power filtering circuits
- DC-DC converter input or output stages
Fixed Inductors Procurement Notes
Verify the specific ordering suffix to confirm tolerance designation, as variations may exist within the product line. Ensure that the selected component meets RoHS compliance requirements if applicable to your manufacturing standards. Cross-reference the datasheet specifications against your circuit's thermal and current constraints before finalizing procurement decisions.
Fixed Inductors Selection Notes
Select this component for applications requiring a compact shielded inductor capable of handling up to 2.8 A. Consider the 195 mΩ DC resistance for efficiency calculations in low-voltage power paths. The wide operating temperature range supports use in demanding industrial environments where thermal stability is critical for consistent performance.
Fixed Inductors Part Context
This part belongs to the CTMMP series of fixed inductors from Central Technologies. The series offers various inductance values tailored for power electronics. The CTMMP1805F-4R7M specifically targets mid-range current applications in space-constrained designs, providing a balance between electrical performance and physical footprint compared to larger unshielded alternatives.
Fixed Inductors Replacement Considerations
Direct substitutes must match the 4.7 µH value, 2.8 A current rating, and SMD form factor. Verify that alternative components offer comparable shielding effectiveness and operate within the same -55°C to +125°C temperature range to ensure system reliability.
