CTMMP1808AF-150M

Fixed Inductors Overview

The CTMMP1808AF-150M is a surface-mount shielded power inductor manufactured by Central Technologies. It features a nominal inductance of 15 µH with a tolerance of ±20%. The component has a maximum rated current of 1.9 A and a DC resistance (DCR) characteristic typical for the series. It utilizes a shielded design to minimize electromagnetic interference.

Fixed Inductors Feature Summary

• Surface mount package configuration
• Shielded magnetic structure
• Power inductor application

Fixed Inductors Applications

• DSP controller motor control applications
• Real-time system stability circuits
• Power supply filtering

Fixed Inductors Procurement Notes

Verify the specific part number CTMMP1808AF-150M against official Central Technologies documentation to confirm active status and electrical parameters. Ensure compatibility with surface mount assembly processes and thermal requirements for the intended power inductor application.

Fixed Inductors Selection Notes

Select this component for applications requiring a 15 µH inductance value with a 1.9 A current rating. Consider the shielded design for environments sensitive to electromagnetic interference. Verify that the surface mount footprint matches the PCB layout constraints.

Fixed Inductors Part Context

This part belongs to the CTMMP1808AF series of shielded power inductors from Central Technologies. The series offers various inductance values suitable for power management and signal processing circuits, providing reliable performance for industrial and consumer electronics.

Fixed Inductors Replacement Considerations

Public confirmed substitute part numbers are not available in the provided source material. Consult manufacturer catalogs for cross-reference options if direct replacement is required.
