CTMMP2205AF-1R0M is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Central Technologies. Its product description is SMD Shielded Power Inductor. Review the specifications below when checking this part for your BOM.
Fixed Inductors specifications for CTMMP2205AF-1R0M
- Description：SMD Shielded Power Inductor
- Series：-
- Mfr：Central Technologies
- Package：Bulk
- Type：-
- Material - Core：-
- Inductance：1 µH
- Tolerance：±20%
- Current Rating (Amps)：4.4 A
- Current - Saturation (Isat)：-
- Shielding：Shielded
- DC Resistance (DCR)：44.3mOhm
- Q @ Freq：-
- Frequency - Self Resonant：-
- Ratings：-
- Operating Temperature：-55°C ~ 125°C
- Inductance Frequency - Test：-
- Mounting Type：Surface Mount
- Package / Case：-
- Supplier Device Package：-
- Size / Dimension：0.216" L x 0.204" W (5.49mm x 5.18mm)
- Height - Seated (Max)：0.047" (1.20mm)
- Features：-
Fixed Inductors datasheet and documents for CTMMP2205AF-1R0M
Fixed Inductors Overview
The CTMMP2205AF-1R0M is a shielded surface-mount power inductor manufactured by Central Technologies. It features a nominal inductance of 1 µH with a tolerance of ±20%. The component has a typical DC resistance (DCR) of 44.3 mΩ, an RMS current rating (Irms) of 4.4 A, and a saturation current (Isat) of 4.4 A. These electrical characteristics define its performance for general-purpose inductive applications.
Fixed Inductors Feature Summary
- Shielded construction to minimize electromagnetic interference
- Surface-mount design for automated assembly integration
- High current handling capability suitable for power circuits
Fixed Inductors Applications
- Power supply filtering
- DC-DC converter input/output stages
- General-purpose signal processing
Fixed Inductors Procurement Notes
Verify the exact part number against official Central Technologies documentation to ensure compatibility. Confirm that the specified electrical parameters, including inductance and current ratings, align with your circuit requirements before procurement.
Fixed Inductors Selection Notes
Select this component based on its specific 1 µH inductance and 4.4 A current ratings. Ensure the application environment supports surface-mount technology and that the shielded package meets the necessary electromagnetic compatibility standards for the intended design.
Fixed Inductors Part Context
This component belongs to the CTMMP2205AF series of fixed inductors from Central Technologies. The series offers various inductance values within a standardized surface-mount footprint, providing consistent mechanical and electrical characteristics across different product variants.
Fixed Inductors Replacement Considerations
Cross-reference with other SMD shielded power inductors offering 1 µH inductance and similar current ratings. Verify pinout compatibility and thermal performance specifications when considering alternative manufacturers.
