CTMMP2207F-1R0M is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Central Technologies. Its product description is SMD Shielded Power Inductor. Review the specifications below when checking this part for your BOM.
Fixed Inductors specifications for CTMMP2207F-1R0M
- Description：SMD Shielded Power Inductor
- Series：-
- Mfr：Central Technologies
- Package：Bulk
- Type：-
- Material - Core：-
- Inductance：1 µH
- Tolerance：±20%
- Current Rating (Amps)：9:00 AM
- Current - Saturation (Isat)：-
- Shielding：Shielded
- DC Resistance (DCR)：17mOhm
- Q @ Freq：-
- Frequency - Self Resonant：-
- Ratings：-
- Operating Temperature：-55°C ~ 125°C
- Inductance Frequency - Test：-
- Mounting Type：Surface Mount
- Package / Case：-
- Supplier Device Package：-
- Size / Dimension：0.213" L x 0.224" W (5.40mm x 5.70mm)
- Height - Seated (Max)：0.071" (1.80mm)
- Features：-
Fixed Inductors datasheet and documents for CTMMP2207F-1R0M
Fixed Inductors Overview
The CTMMP2207F-1R0M is a shielded surface-mount power inductor from Central Technologies. It features a nominal inductance of 1 µH with a metal molded construction. The component is designed for high-current applications, supporting a maximum rated current of 8.5 A and a saturation current of 13.5 A. It exhibits a low DC resistance of 0.014 Ω and operates within a temperature range of -55°C to +125°C. The device is RoHS compliant and lead-free.
Fixed Inductors Feature Summary
- Shielded magnetic design minimizes electromagnetic interference
- Metal molded construction ensures mechanical stability
- High current handling capability for power filtering
- Surface mount package facilitates automated assembly
Fixed Inductors Applications
- DC-DC converter output filtering
- Power supply input chokes
- Current mode control circuits
- Energy storage in switching regulators
Fixed Inductors Procurement Notes
Verify the manufacturer part number against official Central Technologies documentation to confirm specifications. Ensure compliance with RoHS directives and lead-free requirements as stated in the datasheet. Check for any specific handling or storage conditions required for surface mount components. Confirm that the selected variant matches the required inductance and current ratings for the target application.
Fixed Inductors Selection Notes
Select this component when a compact, shielded inductor is required for high-current power stages. The 1 µH value and 8.5 A rating suit applications needing efficient energy storage with minimal size. Consider the operating temperature range and DC resistance for thermal management. Verify footprint compatibility with the PCB layout before integration.
Fixed Inductors Part Context
This part belongs to the CTMMP2207F series of shielded power inductors. The series offers various inductance values tailored for different power conversion needs. Central Technologies designs these components to balance performance and size for modern electronics.
Fixed Inductors Replacement Considerations
Consult the official datasheet for direct substitutes within the CTMMP2207F series. Cross-reference parameters such as inductance, tolerance, current ratings, and physical dimensions to ensure functional equivalence.
