CTMMP2707F-R82M is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Central Technologies. Its product description is SMD Shielded Power Inductor. Review the specifications below when checking this part for your BOM.
Fixed Inductors specifications for CTMMP2707F-R82M
- Description：SMD Shielded Power Inductor
- Series：-
- Mfr：Central Technologies
- Package：Bulk
- Type：-
- Material - Core：-
- Inductance：0.82 µH
- Tolerance：±20%
- Current Rating (Amps)：14 A
- Current - Saturation (Isat)：-
- Shielding：Shielded
- DC Resistance (DCR)：15.9mOhm
- Q @ Freq：-
- Frequency - Self Resonant：-
- Ratings：-
- Operating Temperature：-55°C ~ 125°C
- Inductance Frequency - Test：-
- Mounting Type：Surface Mount
- Package / Case：-
- Supplier Device Package：-
- Size / Dimension：0.287" L x 0.268" W (7.30mm x 6.80mm)
- Height - Seated (Max)：0.071" (1.80mm)
- Features：-
Fixed Inductors datasheet and documents for CTMMP2707F-R82M
Fixed Inductors Overview
The CTMMP2707F-R82M is a shielded power inductor from Central Technologies, featuring an inductance of 0.82 µH and a maximum current rating of 44 A. It exhibits a DC resistance of 3 mOhm and operates within a temperature range of -55°C to +125°C. The component utilizes a surface-mount package design suitable for high-current applications.
Fixed Inductors Feature Summary
- Shielded magnetic structure minimizes electromagnetic interference
- High current handling capability for power supply circuits
- Low DC resistance reduces power loss and heat generation
Fixed Inductors Applications
- DC-DC converter output filtering
- Point-of-load (POL) power regulation
- High-current buck converter stages
Fixed Inductors Procurement Notes
Verify the specific suffix 'R82M' corresponds to the 0.82 µH value during procurement. Confirm RoHS compliance status with the supplier. Ensure the ordering information matches the exact part number to avoid receiving variants with different current ratings or inductance values.
Fixed Inductors Selection Notes
Select this component when high saturation current is required alongside compact surface-mount packaging. The low DCR makes it suitable for efficiency-critical designs. Evaluate thermal performance at full load conditions given the 44 A rating.
Fixed Inductors Part Context
This part belongs to the CTMMP series of shielded power inductors. The series offers various inductance values optimized for different current requirements. The CTMMP2707F variant specifically denotes the physical dimensions and shielding type used in this model.
Fixed Inductors Replacement Considerations
Cross-reference with other shielded power inductors offering similar 0.82 µH inductance and comparable current ratings. Verify pin compatibility and footprint dimensions before substitution.
